Pvc Membrane | Roofing - PVC Single Ply Roofing Systems
Categories
Special Products
- Drinking Water
- Reservoirs and Tanks as Top Layer
- Water Channels and Water Tanks as Top Layer
- Drinking and Potable water transmission systems
- High Quality meeting EN 13967 Quality Standards
- Vapor Permeable structure
- Antimicrobacterial Features
- Does not change of water physical and chemical properties
- Does not permit generation of bacteria and mosses on the surface.
- Recyclable environment-friendly material that includes no heavy metal
- High flexibility value.
- Dimensionaly stable material
- Ability to maintain its flexibility in -25C degrees temperature
- High tear resistance and impact strength
- Qualified and easy application options with heat air welder
- Provides waterproofing in temperatures between -35 C and +85 C degrees
- Homogeneous product that has dissolution and decomposition resistances.
Tested Features | Minimum Required Value | Test Result | Unit | Test Method |
Waterproofing | impermeable | impermeable | - |
EN
1928 (B) |
The end of the aging water resistance | impermeable | impermeable | - |
EN
1926 ve EN 1928
(A) |
Determination of visible defect | perfect | perfect | - |
EN
1850-2 |
Value of tensile strength | >15 |
>18 |
N/mm2 | EN
12311-2 |
Value of elasticity | >250 |
>320 |
% |
EN12311-2 |
Static Load Resistance Value | >20 |
>20 |
Kg |
EN
12730 (B) |
Value of Impact Resistance | >450 |
>900 |
mm |
EN
12691 (A) |
Tear Strength Value | >300 |
>330 |
N |
EN 12310-1 |
Reaction to Fire | E Class | E Class | - |
EN 13501-1 |
Value of joint strength | >600 |
>750 |
N/50mm |
EN 12317-2 |
Determination of Water Vapor Permeability | 25500 ±
7500 |
25500 ± 7500 | µ |
EN 1931 |
Junction Where The Value of Peel Strength | >150 |
>155 |
N/50mm |
EN 12316-2 |
Dimensional Stability | <2 |
<2 |
% |
EN 1107-2 |
Stability of Elasticity in The Cold | <
-25 |
<
-25 |
°C |
EN 495-5 |
PRODUCT SIZES
Thickness | Width | Length | Colour* |
Roll m2 |
Roll Weight |
1,2mm |
2,10mt |
25 |
Blue |
52,5m2 | 82kg |
1,5mm |
2,10mt |
20 |
Blue | 42m2 | 98kg |
