| Tested Features |
MMinimum Required Value |
Test Result |
Unit |
Test Method |
|
Determination of visible defect
|
perfect
|
perfect
|
-
|
EN 1850-2
|
|
External Fire Resistance
|
BRoof (t1)
|
Feasible
|
-
|
EN 13501-5
|
|
Reaction to Fire
|
E Class
|
E Class
|
-
|
EN 13501-1
|
|
Waterproofing
|
impermeable
|
impermeable
|
-
|
EN 1928 (B)
|
|
Plant Root Resistance
|
Feasible
|
Feasible
|
-
|
EN 13948
|
|
UV Resistance( 1000 h )
|
Strength
|
Strength
|
-
|
EN 1297
|
|
Value of joint strength
|
>600
|
>800
|
N/50 mm
|
EN 12317-2
|
|
Static Load Resistance Value
|
>20
|
>25
|
Kg
|
EN 12730 (B)
|
|
Value of elasticity
|
>15
|
>21
|
%
|
EN 12311-2
|
|
Value of Impact Resistance
|
>400
|
600
|
mm
|
EN 12691 (A)
|
|
Tear Strength Value
|
>180
|
>320
|
N
|
EN 12310-2
|
|
Value of tensile strength
|
>800
|
>1000
|
N/50 mm
|
EN 12311-2
|
|
Junction Where The Value of Peel Strength
|
>200
|
>280
|
N/50 mm
|
EN 12316-2
|
|
Stability of Elasticity in The Cold
|
<-25
|
<-25
|
°C
|
EN 495-5
|
|
Dimensional Stability
|
< 1
|
< 1
|
%
|
EN 1107-2
|
|
Full grain Strength
|
>17
|
>22
|
m/s
|
EN13583
|
PRODUCT SIZES
| Thickness |
Width |
Length |
Colour * |
Roll m2 |
Roll Weight |
| 1,1 mm |
2,10 mt |
30 |
Grey/Black |
63 m2 |
83 kg |
| 1,2 mm |
2,10 mt |
30 |
Grey/Black |
63 m2 |
90 kg |
| 1,5 mm |
2,10 mt |
20 |
Grey/Black |
42 m2 |
75 kg |
| 1,8 mm |
2,10 mt |
15 |
Grey/Black |
31,5 m2 |
75 kg |
( * ) Different Colours Are Possible According To Demand
|
|
|
|
